14.3kWh GoodWe Low Voltage Battery

Specifications

• Model: GW14.3-BAT-LV-G10
• Rated Energy: 14.3kWh
• Usable Energy: ≥13.8kWh
• Battery Type: LFP (LiFePO₄)
• Nominal Voltage: 51.2V
• Max Continuous Charging Current: 224A
• Max Continuous Discharging Current: 260A
• Max Input Power (System): 12kW
• Max Output Power (System): 12kW (13.2kW for 10 min)
• Peak Output Power: 20kW @ 15 seconds
• Charging Temperature Range: 0°C to +55°C
• Discharging Temperature Range: –20°C to +55°C
• Relative Humidity: 5% – 85%
• Max Operating Altitude: 4000m
• Communication: CAN, RS485
• Ingress Protection: IP20
• Weight: 125kg
• Dimensions (No Base): 530 × 885 × 246 mm
• Dimensions (With Base): 530 × 918.6 × 246 mm
• Optional Features: Aerosol fire suppression
• Ambient Temperature (Standard): 0°C to +45°C
• Ambient Temperature (Recommended): +10°C to +35°C
• Storage Time: • 12 months from –20°C to +35°C • 6 months from +35°C to +45°C
• Mounting: Wall-Mounted / Floor-Mounted
• Certifications: IEC 62619, IEC 63056, IEC 60730-1 EMC: EN IEC61000-6-1 / -6-2 / -6-3 / -6-4 UN38.3, ADR, MSDS
